| D42-SNO28$83.25 | |
|---|---|
| Switch Type | Electrical |
| Actions | Single Stage Momentary |
| Circuitries | SPST-NO (Form "A") |
| Cable Entries | Adjustable strain relief clamp |
| Cordsets | 8-ft cordset, no plug |
| Housing Colors | Black |
| Housing Materials | Polymeric |
| Switch Connections | Pre-wired |
| Electrical Ratings | 3A, 125 VAC, 5 A Resitive, 125 VAC, 5A, 28 VDC, Standard Pilot Duty 125 VAC Max. |
Dolphin
$83.25
Drip Tight • Dust Tight • Watertight • Corded
INTENDED FOR INDOOR USE PRIMARILY TO PROVIDE A DEGREE OF PROTECTION AGAINST THE ENTRY OF WATER DURING OCCASIONAL TEMPORARY SUBMERSION AT A LIMITED DEPTH.
Price Reflects US orders only
Enclosure
NEMA Type 2, 4, 6 & 6P • EN 60529 Degree of Protection • IP68 • Meets IEC 60601-2-2
Purpose
High Impact Low Profile Omni-Directional Design
Features & Benefits
- Low profile to aide in elimination of fatigue
- A nonskid base pad
- Wired normally open, no ground
Materials
- Actuation from any direction with moderate pressure
- The cover and base is molded in a high impact polymeric compound
- Base includes mounting provisions
Download product data sheet
More Information
| D42-SNO28$83.25 | |
|---|---|
| Switch Type | Electrical |
| Actions | Single Stage Momentary |
| Circuitries | SPST-NO (Form "A") |
| Cable Entries | Adjustable strain relief clamp |
| Cordsets | 8-ft cordset, no plug |
| Housing Colors | Black |
| Housing Materials | Polymeric |
| Switch Connections | Pre-wired |
| Electrical Ratings | 3A, 125 VAC, 5 A Resitive, 125 VAC, 5A, 28 VDC, Standard Pilot Duty 125 VAC Max. |
